OUT LATEST NEW PRODUCT WITH MULTIPURPOSE NEEDS.

INNOSTRA is a new numerical control machine  from us that have various functions such a milling, laser cutting, laser engraving, 3D printing.

FEATURES

Engraving Spindle

Engrave your product more efficient and saving time.

3D Printing Module

Print your prototype more precise.

Laser System

Productivity Up with our laser system.

SEE OUR VIDEO PRODUCT

MACHINE SPECIFICATION DETAIL

Detail Specification

  • Control System* : Siemens 808D/Delta NC300
  • Overal Size (L x W x H ) : 1560 x 1824 x 2089 mm
  • Weight : 1500 kg
  • Electricity : 220 v Single Phase
  • Function : Milling, Laser Engraving, 3D printing
  • Axis Motor Power : 750 W
  • Max. Feed Rate : 2000mm/ min

Detail Specification

  • Size Working Area : 250 x 250 x 250 mm
  • Max. Working Load : 100 kg
  • T Slot Type : DIN 787 070 -104 , DIN 508 226 - 401
  • T Slot Size/Num/Dis : 18 mm/3/90 mm
  • Table Dimension : 510 x 350 mm

Detail Specification

  • Operating Speed : 8000 - 24000 RPM
  • Power : 2,2 KW
  • Collet : ER 20
  • Lubrication : Oil Grease

Detail Specification

  • Cooling : Air Cooling
  • Laser Unit : 40 W
  • Transfer System : Mirror Set Modular System
  • Coolant System : Water Cooled Radiator

Detail Specification

  • System : FDM Type
  • Extruding Module : 3D Extruder Drive by Sevo Motor
  • Extruding Material : ABS/PLA

MEET THE ENGINEER

“

The manufacturing industry has undergone many significant changes. With the development of multifunctional machine tools. We also develop multifunctional machine tools that can facilitate you in the production process in your workshop area.

             Febri Setianto
